Panasonic Electric Works
BBD1321CNTF
MCB 32A Single Pole 1P1E, DIN Rail, 6kA, Cable/Pin-typebusbar, BBD1321CNTF
Specifications
Model No:
BBD1321CNTF
| Reference Standard |
IEC60898-1 |
|---|---|
| Rated impluse withstand voltage(1.2/50)(Uimp) |
4000V |
| Rated short-circuit capacity(lcn) |
6kA |
| Mechanical endurance |
20,000 cycles |
| Electrical endurance |
4000 Cycles |
| Protection degree |
IP20 |
| Operating Temperature |
-10°C ~ 60°C |
| Terminal connection type |
Cable/Pin-type busbar |
| Connections |
1mm² to 25mm² for Cuconductors |
| Tightening torque |
2Nm22In-lb |
| Status display |
On:Red Off:Green |
| Standards |
IEC |
| Certification |
RoHS |
