Panasonic Electric Works
BBDS340HF
Isolator 40A Three Pole 3P, DIN Rail, -, Cable/Pin-type busbar, BBDS340HF
Specifications
Model No:
BBDS340HF
| Reference Standard |
IEC60947-3 |
|---|---|
| Rated impluse withstand voltage(1.2/50)(Uimp) |
6000V |
| Rated short-circuit capacity(lcn) | |
| Mechanical endurance |
30000 |
| Electrical endurance |
20000 Cycles |
| Protection degree |
IP20 |
| Operating Temperature |
-10°C ~ 60°C |
| Terminal connection type |
Cable/Pin-type busbar |
| Connections |
40A/63A: 4sq.mm to 25sq.mm for Cu conductors 100A: 10sq.mm to 50sq.mm for Cu conductors |
| Tightening torque |
2.5 Nm |
| Status display |
On:Red Off:Green |
| Standards |
IEC |
| Certification |
RoHS |
